Infrastructure

Ten micro lysimeters, built by JR-AquaConSol GmbH, Graz, Austria, with soil monoliths, continuous weighing, soil moisture measurement at three depths with tensiometers and water content sensors, and suction cups to simulate capillary rise.

The following video shows how the micro lysimeter facility was created (german):
https://youtu.be/wiwLIYs8NvU

The project was funded by the European Regional Development Fund as part of the EU’s response to the COVID pandemic.

Soil monolith in lysimeter container
Soil monolith in lysimeter container
Lysimeters equipped with sensors
Lysimeters equipped with sensors
Micro lysimeter with 80 cm diameter and 60 cm depth, installed at ground level
Micro lysimeter with 80 cm diameter and 60 cm depth, installed at ground level
Service chamber with leachate tank and electronic control cabinets
Service chamber with leachate tank and electronic control cabinets
Irrigation trolley for individual irrigation of max. 160 plots
Irrigation trolley for individual irrigation of max. 160 plots

Gierhake irrigation trolley with Coldewey control system for individual irrigation of max. 160 plots



Climate chambers HGC 0714, Weiß-Technik
Climate chambers HGC 0714, Weiß-Technik

Four climate chambers HGC 0714, Weiß-Technik, are available for experiments on the effect of temperature, humidity, irradiation and CO2 content.
https://www.weiss-technik.com/de/produkte/produkte-detail/modulare-pflanzenwuchsschraenke-fitotronr-typ-hgc



Eddy covariance system, Li-Cor, measuring the evapotranspiration of spinach
Eddy covariance system, Li-Cor, measuring the evapotranspiration of spinach

Eddy covariance system, LI-COR Inc., for measuring evapotranspiration under field conditions
https://www.licor.com/env/products/eddy_covariance/



Gas exchange meter GFS3000 from Walz for determining the transpiration and assimilation in an asparagus field
Gas exchange meter GFS3000 from Walz for determining the transpiration and assimilation in an asparagus field

Gas exchange meter GFS3000, Heinz Walz GmbH, for determining the transpiration and assimilation of plants
https://www.walz.com/products/gas_exchange/gfs-3000/introduction.html



Scholander pressure chamber "PWSC", soilmoisture.com
Scholander pressure chamber "PWSC", soilmoisture.com

Scholander pressure chamber "PWSC", Soilmoisture Equipment Corp., for measuring plant water potential under laboratory conditions
http://www.soilmoisture.com/3005-Series-Plant-Water-Status-Consoles/



Scholander pressure chamber Pump-Up chamber, PMS Instrument Company
Scholander pressure chamber Pump-Up chamber, PMS Instrument Company

Scholander pressure chamber "Pump-Up chamber", PMS Istrument Company, for measuring plant water potential under field conditions.
https://www.pmsinstrument.com/products/pump-up-pressure-chamber/
